Glass Strength Bend Test Equipment
$35000.00$34000.00
Glass Strength Bend Test Equipment
Overview
The Glass Strength Bend Test Equipment is designed for accurate measurement of the flexural and tensile strength of glass materials. It performs three-point or four-point bending tests to evaluate the mechanical strength, fracture resistance, and overall performance of flat, tempered, or laminated glass. This system is ideal for R&D laboratories, quality control departments, and certification facilities involved in glass production and processing.
Key Features
Performs both three-point and four-point bending tests in compliance with international standards (ISO, ASTM, EN).
High-precision load cells and displacement sensors ensure accurate and repeatable measurements.
Suitable for a wide range of glass types: float glass, tempered glass, laminated glass, and coated glass.
Adjustable support span for testing various sample sizes and thicknesses.
PC-controlled operation with real-time data acquisition, curve plotting, and automatic calculation of bending strength.
Strong, rigid test frame for stability and safety during high-load testing.
Optional environmental chamber for temperature or humidity-controlled tests.
Typical Specifications
Test Method: 3-point / 4-point bending test
Load Capacity: 1 kN – 100 kN (customizable)
Span Adjustment: 50 mm – 1000 mm (depending on model)
Accuracy: ±0.5% of indicated load
Crosshead Speed: 0.05 – 500 mm/min
Displacement Resolution: 0.001 mm
Power Supply: 220V AC / 50 Hz
Data Output: USB, Ethernet, or RS-232 (CSV, PDF, Excel report formats)
Applications
Mechanical strength testing of architectural and automotive glass
Evaluation of tempered and laminated glass quality
Research on fracture behavior and surface treatment effects
Quality control for glass manufacturers and certification bodies
Benefits
Delivers precise, repeatable, and traceable strength data
Conforms to international testing standards (ASTM C158, ISO 1288, EN 1288)
Flexible design accommodates different glass sizes and shapes
Intuitive software interface for data analysis and reporting
Reliable results for R&D, production testing, and certification
